China 36*1W/3W RGB/Wa Waterproof LED PAR Light (IP 65)

Product Description

This LED light adopts in 36*1W/3W, which is the most advanced lamp as light sources. It is new generation green high technology product. It projects long distance, big angle, and abundant colors. It brings people new vision sense, which makes people feel they are in a changeable color world.

The nice design is good for dispelling heat very well and long life. Project angle can be adjusted randomly. The base is with holes, which are facility for orientation and fitting.

It is widely used in stage show, casino, advertisement, outside wall of mansion etc. It is controlled by controller with DMX; The effect can be gradual change, jump change, color glitter, random change, and alternate gradual change and so on. Perfect cast light beam provides architecture designers and light designers abundant imagine space.

Specification:
Model	LED 1005/LED 1005-3W
Housing Material	Aluminum
Housing Color	Black/White
Aperture Cover	PMMA
Operating voltage	90-254V AC
Power	Switch Power Supply
LED current	320mA
Control Modes	Direct DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronization
DMX Channel	6CH/3CH
Control panel	Digital 4 characters alphanumeric
Connector	3-PinXLR (In and Out)
NO.of LED	36*1W/3W LEDS (12R/ 12B/ 12G)
LED Life Time	80000-100,000 hours
Beam Angle	25°/30°
Power Consumption	45W/120W
Light Projecting Distance	10-15M
IP Rating	Outdoor, IP 65
Operating Temperature	-20ºC+45ºC
Dimensions	L260*Ø200 mm
Weight	4.80KGS
Packing Dimension	L27W27H37 cm
Gross Weight	5.00KGS
Compatibility:
1. Color Range :16.7 million additive RGB colors; continuously variable intensity (256×256×256=16777216)
2. Dimming 0-100%with regulated constant color control
3.Strobe: 10 Flashed per second (any color)
4. Function: it is max mix color, color change, color's gradual change, flash, speed/luminance the adjustable
5. 6channel Mode and 3channel Mode would change each other in every light
6. 6CH Mode DMX Value	CH 1 _ General dimmer (1-255, from dart to light)
	CH 2_ Red (1-255, Dimmer, from dart to light)
	CH 3 _ Green (1-255, Dimmer, from dart to light)
	CH 4_Blue (1-255, Dimmer, from dart to light)
	CH 5_ Strobe & Color change/ color gradual change open
	CH 6 _Strobe & Color change& color gradual change's speed adjustment (1-255, Speed adjustment, from slow to fast)
7. 3CH Mode DMX Value	CH 1_ Red (1-255, Dimmer ,from dart to light)
	CH 2 _ Green (1-255, Dimmer,from dart to light)
	CH 3_Blue (1-255, Dimmer,from dart to light)
8.Control modes	0: sound activity mode
	1. DMX control mode
	2. Adjusting the color manual
	3. Adjusting the brightness manual
	4. Adjusting the strobe manual
	5. Adjusting the strobe speed manual
	6. Master-slave control mode, as the master
	7. Sound activity synchronization mode
	8 .Adjusting color's gradual change manual
	9. Adjusting gradual change's speed
Each Package Included:
1 * LED 1005 LED PAR 64 with Signal Cable :3-PinXLR DMX In and Out + Water Power cable: Power Cable screw water proof connectors in and out (2 ft cable)
1*Power cable: 3 Pin plug and screw water proof connector on other side. (5ft = 1.5m)
1 * User Manual
2* pyrocondensation.cannula (0.66ft = 20cm)
1* Waterproof connector's cover for Power cable
